7TBRP Developed Coils Available for 7T Neuroimaging
Designed, developed, and assembled by the 7TBRP
- Upgraded 2nd Generation Tic-Tac-Toe RF Head Coil System (Tac G2 Plus)
- 60 Transmit Channels
- 32 Receive Channels
- Designed for 7T pTx (2-minute swap to sTx mode)
- Largest Rx Head Coil Size at 7T
- EEG Capable
- Open from above the eyes down (see below)
- Front and Rear Projection Ready
- Extended coverage to C6 on T1- and T2-weighted sequences
- 2nd Generation Tic-Tac-Toe RF Head Coil System (Tac G2)
- 60 Transmit Channels
- 32 Receive Channels
- Designed for 7T sTx mode (pTx Capable)
- Open from above the eyes down (see below)
- Front and Rear Projection Ready
- Extended coverage to C6 on T1- and T2-weighted sequences
- Used in > 35 NIH funded studies on the sTx mode without subject-specific RF shimming
- 1st Generation Tic-Tac-Toe RF Head Coil System (Tac G1)
- 16 Transmit Channels
- 32 Receive Channels
- Designed for 7T sTx mode (pTx Capable)
- Used in > 30 NIH funded studies on the sTx mode without subject-specific RF shimming
Commercial Coils Available for 7T Neuroimaging
- Rapid Biomedical Dual Tuned 31P-1H RF Head Coil System
- 2 Transmit Channels (sTx mode only)
- 2 Receive Channels
- Nova Medical RF Head Coil System
- 1 Transmit Channel (sTx mode only)
- 32 Receive Channels
- Research Only Version
Clinically Approved 7T Coils for use on Terra.X
- Nova Medical RF Head Coil System
- 8 Transmit Channels (pTx/8Tx)
- 32 Receive Channels
- QED Knee Coil System
- 1 Transmit Channel (sTx mode only)
- 28 Receive Channels
Other Tic-Tac-Toe Coils
Designed, developed, and assembled by the 7TBRP
- 7T Tic Tac Toe Foot/Ankle Coil System
- 1-4 Transmit Channels (pTx and sTx capable)
- 4 Receive Channels
- 7T Tic Tac Toe Body Coil System
- 1-32 Transmit Channels
- 16 Receieve Channels
- 7T Tic Tac Toe Breast Coil System
- 1-8 Transmit Channels
- 8 Receive Channels
Legacy 7TBRP Coils
Designed, developed, and assembled by the 7TBRP
- 7T TEM Knee Coil System
- 1-4 Transmit Channels (pTx and sTx capable)
- 8 Receive Channels
- 7T TEM Hand/Arm Coil System
- 1-4 Transmit Channels
- 8 Receive Channels
- 7T TEM Head Coil System
- 4 Transmit Channels (pTx and sTx capable)
- 14 Receive Channels
- 3T Dual Tuned 31P/1H Coil System
31P:
- 1 Transmit Channel
- 4 Receive Channels
1H:
- 1 Transmit Channel
- 1 Receive Channel
